RoHS Practical CCA Cat6a LSZH Cable SFTP FTP UTP PVC Bare Copper

Certification
China Dongguan Blue Eye Cat Technology Co., Ltd. certification
China Dongguan Blue Eye Cat Technology Co., Ltd. certification
I'm Online Chat Now

RoHS Practical CCA Cat6a LSZH Cable SFTP FTP UTP PVC Bare Copper

RoHS Practical CCA Cat6a LSZH Cable SFTP FTP UTP PVC Bare Copper
RoHS Practical CCA Cat6a LSZH Cable SFTP FTP UTP PVC Bare Copper

Large Image :  RoHS Practical CCA Cat6a LSZH Cable SFTP FTP UTP PVC Bare Copper

Product Details:
Place of Origin: P.R.C
Brand Name: Blue Eyes Cat/OEM/ODM
Certification: RoHS REACH CE UL
Model Number: BEC 6A09
Payment & Shipping Terms:
Minimum Order Quantity: 100
Packaging Details: Individual package size LxWxH: 400*400*240mm Carton size LxWxH: 490x430x420 mm
Delivery Time: 7-12working days
Payment Terms: T/T, Western Union
Supply Ability: 10000

RoHS Practical CCA Cat6a LSZH Cable SFTP FTP UTP PVC Bare Copper

Description
Type: CAT6A LAN Cable Number Of Conductors: 8
Conductor Size: 23AWG/24AWG/26AWG Conductor Material: BCBC, CCC, CCA, CU, CCS, CCAU
Insulation: HD-PE Jacket Material: PVC /LSZH
Color: Black, White, Blue, Grey, Red Length: 305m/1000ft Box Per Pull Box
Packing: 2 Box / Carton
High Light:

RoHS Cat6a LSZH Cable

,

Practical Cat6a LSZH Cable

,

Copper Cat6a SFTP Cable

LSZH BC Cat6a Lan Cable SFTP/FTP/UTP PVC Bare Copper CCA Bulk Network Cable



  • HIGH PERFORMANCE NETWORK CABLE. This riser rated cat 6A lan cable is 23 AWG with 4 pairs (8C). The overall aluminum (AL) foil shield helps eliminate cross-talk and prevents electromagnetic interference (EMI). Suitable for 1 Gigabit and 10-Gigabit Ethernet speeds up to 328 feet. Bandwidth tested up to 750 MHz. Supports
  • Power over Ethernet: PoE/PoE+/PoE++ (IEEE 802.3af/at/bt) 4PPoE up to 100W.
  • HASSLE FREE PACKAGING. 1000 feet (305 meters) has been packaged on a tangle free, easy pull reel/spool so you don’t have to worry about getting behind on your next job.
  • SOLID BARE COPPER CONDUCTORS. Pure bare copper produces a stronger signal along with better conductivity and flexibility when compared to copper clad aluminum (CCA).
  • FOR USE INDOORS. The blue riser rated jacket is for use in between floors, in wall, and non-plenum spaces. Help fires from spreading floor to floor in vertical installations with mild flame retardance.
  • CERTIFIED .Our data cables have been tested with a Fluke DSX-8000 Versiv CableAnalyzer and are in compliance with ANSI/TIA 568.2-D standards, RoHS-3 compliant.



Features

Double shielded LAN installation cable with solid wires
High quality full copper conductors
Category 6a



Specifications

Conductor material: 23AWG

HDPE insulation of the wire: 1.0 mm
PVC outer insulation: 6.5 mm
Operation up to 500 MHz High-speed 10Gbps
Length: 1000 ft (305 m)
Package: Reelex box
Color: black, white, blue, grey
Conductor resistance (max): 90 ohm/ 1000m
Insulation resistance (min): 5M ohm/km
Pair-to-Ground capacitance: < 330PF / 100m
Characteristic impedance: < 100Ohm (+/- 15)
Transport and storage temperature: 0 - 60 degrees
Operating temperature: -20 - 70 degrees
Working distance: <100m




Model
SFTP Cat7 lan Cable
Conductor Size
26AWG,24AWG,23AWG,22AWG (Customized)
Conductor Material BC/CU/CCA (Optional)
No.of Conductor
4 Pairs
Insulation Material
HDPE or Skin-foam-skin insulation
Insulation Thickness
0.2mm
Insulation Diameter
1.0mm(±0.02mm)
Jacket Thickness
0.92-0.95mm
Jacket Material
PVC, LSZH
Jacket Color Grey, Black , Blue, Red, White (Customized)
Shield Double shield / shielded with Al foil +braiding net
Impedance
100 ± 22%Ω
Length
1000ft/roll 305m/roll, 100m/roll (Customized)
Printing Words on Cable Customized
Packing
305m/1000ft, 500m with wooden reel, one roll one carton
Certificates CE, RoHS, FCC
Operating Temperature -40 °C - +70 °C
Application
Computer/Switch/Hubs/Router



Note

BC: Bare Copper
CCS: Copper Clad Steel
CCA: Copper Clad Aluminum
Rated Temperature:75°C
Various lengths and colors are available
Customers' specifications are welcomed.



All BC Network Lan Cable Pass FlukeTest 100%

RoHS Practical CCA Cat6a LSZH Cable SFTP FTP UTP PVC Bare Copper 0

RoHS Practical CCA Cat6a LSZH Cable SFTP FTP UTP PVC Bare Copper 1

RoHS Practical CCA Cat6a LSZH Cable SFTP FTP UTP PVC Bare Copper 2

RoHS Practical CCA Cat6a LSZH Cable SFTP FTP UTP PVC Bare Copper 3





Packing & Shipping
1) Packing Lengths: 100/roll, 200m/roll, 300m/roll, 305m/roll, 500m woden reel, 1000m wooden reel
2) Inner Packing: Wooden reel, plastic reel, and paper reel
3) Outer Packing: Carton box, pull out box, pallet available
4) Other packing available according to clients' request
5) Usually we deliverour products by Sea. Other delivery methods are available upon request from clients.



Our service
1) Quick Response -- All inquiries will be replied within 24 hours.
Professional Quotation -- All pricing will be quote according to customers' detailed specifications & requirements.
2) OEM & ODM Service -- Can print your own brand on the cable printing with foot or meter marking. -- Make customized designs for stickers, drums, outer cartons, etc.
3) Stable Quality -- All materials and products passed restrict QC procedures, compliant with international standards.
4) Fast Delivery -- LCL orders, 15 Days after confirmation; FCL orders, 20 days after confirmation.
5) Good After-sales Service -- We chose the fastest vessel to POD for delivery our goods to clients, -- All Documents will be issued according to clients' instructions, to save troubles from local customs. -- Any complaint to quality or packing issued will be responded, and terminated with proper solutions for clients.


What is the process of an order?
Send your detailed request → Feedback with quotation → Confirm quotation and make payment → Make artwork for approval→Make mould→Mold testing→Making samples→Sample testing(Approval) →Mass production→Quality checking→Packing →Delivery →After Service→Repeat Order...





Good after-Sale Service

1) All products will have been strictly Quality Checked in house before packing.
2) All products will be well packed before shipping.
3. Faster delivery
Sample order in stock, and 3-7 days for bulk production.
4. Shipping:
We have strong cooperation with DHL, TNT, UPS, FEDEX, EMS, China Air Post.


FAQ
Q1: Are you a factory or trading company?
A1: We are a manufacturer.
Q2: Where is your factory located? How can I visit there?
A2:Our factory are located in dongguan city.
You can fly to Guangzhou international airport. And tell us your flight No. We will arrange to pick you up.
Q3: May I buy samples from you?
A3: Yes! You are welcome to place sample order to test our superior quality and services.
Q4: What is your Warranty?
A4: All the products will have 12 months Warranty
Q5:What payment method do you accept?
A5:T/T(Bank transfer), , Money Gram, Paypal, etc.
Q6: Can you put my brand name (logo) on these products?
A6: Yes! The professional OEM services will be welcomed to us. Our factory accepts to make the logo free for bulk orders.
Q7: May I know the status of my order?
A7: Yes .The order information and photos at different production stage of your order will be sent to you and the information will be updated in time.
Q8: What’s the leading time? (How long do you need to prepare my goods?
A8: Delivery (no more than 1000pcs) will be arranged within 3-7 days after payment, and arrive you within about 3-7 working days via international express.
Q9: How will you deliver my goods to me?
A9: Your purchases will be delivered by DHL, UPS, FedEx, TNT, EMS your door. Air Cargo and Sea Cargo, Direct line, Air Mail also be accepted according to clients' request.
Q10: Can you provide us more other products to us to help us to save more shipping costs?
A10: Yes.  The OEM bulk order will be accept as well


Our Factory Are Professional Manufacturer In Producing Widely Product Range Cat5/Cat5e/Cat6/Cat6a/Cat7/Cat8
Utp/Ftp/Sftp/Stp Network Cable,





If you have any questions, please contact with us directly. Welcome to visit our factory.
